python-docx Images, Fonts, and Formatting: A Practical Guide

Learn to insert images, set fonts, and control paragraph formatting in Word documents using python-docx. This practical guide covers core APIs, common pitfalls, styles, and compatibility considerations.

~5 min readPython
#python-docx#docx#word-processing#images
A python-docx generated Word document showing an image, styled text, and formatted paragraphs.

When you need to generate Word documents programmatically, python-docx is a widely used library for the job. This article shows how to insert images, control fonts, and apply paragraph formatting reliably. It covers the core APIs, common pitfalls, performance considerations, and ways to keep generated documents maintainable.

Setting Up python-docx and Creating a Document

Start by installing the library:

bash
pip install python-docx

Then create a Document object, which represents a .docx file in memory:

python
from docx import Document doc = Document() doc.save('output.docx')

This gives you a blank document with default styles. Most formatting work happens on two levels: paragraphs and runs. A paragraph is a block of text; a run is a contiguous segment of text with identical formatting. Images live in runs within paragraphs.

Inserting and Positioning Images

To add an image, use add_picture on a paragraph run or directly on the document. The simplest form:

python
doc.add_picture('chart.png')

This places the image in its own paragraph, left-aligned. To control size, set width or height to a document length such as Inches(5). python-docx represents these lengths in EMUs (English Metric Units) and provides Inches and Cm helpers:

python
from docx.shared import Inches doc.add_picture('chart.png', width=Inches(5))

If you specify only width, height scales proportionally. Specifying both can distort the image unless the proportions match the original, so avoid it unless you intentionally need a non-uniform size.

To align an image, access the paragraph that contains it. doc.add_picture() adds the picture to a new paragraph; you can find that paragraph as the last one in the document. A cleaner approach is to create the paragraph first and then add the picture to its run:

python
from docx.enum.text import WD_ALIGN_PARAGRAPH p = doc.add_paragraph() p.alignment = WD_ALIGN_PARAGRAPH.CENTER p.add_run().add_picture('chart.png', width=Inches(4))

This centers the image. For more control, you can also set the picture's position relative to text, but that requires low-level XML manipulation and is rarely needed for typical reports.

Controlling Fonts and Text Formatting

Fonts are applied to runs, not paragraphs. When you add text with add_paragraph, you get a paragraph with a single run. To set font properties, access the run's font attribute:

python
from docx.shared import Pt, RGBColor p = doc.add_paragraph('Important result') run = p.runs[0] run.font.name = 'Calibri' run.font.size = Pt(14) run.bold = True run.italic = False run.font.color.rgb = RGBColor(0x33, 0x66, 0x99)

Pt and RGBColor come from docx.shared. The name property sets the font family. For complex scripts or East Asian fonts, you may also need to set run.font.element.rPr.rFonts attributes, but for standard Latin text, name works.

To apply different formatting within the same paragraph, create multiple runs:

python
from docx.shared import Pt, RGBColor p = doc.add_paragraph() run1 = p.add_run('Total: ') run1.bold = True run2 = p.add_run('$1,234.56') run2.font.size = Pt(16) run2.font.color.rgb = RGBColor(0xCC, 0x00, 0x00)

This is how you mix bold labels with highlighted values. Remember that formatting is per-run, so if you change a paragraph's text later, you must reapply run formatting.

Paragraph Formatting: Alignment, Spacing, and Indentation

Paragraph-level formatting controls the block layout. Common properties include alignment, line spacing, space before/after, and indentation.

python
from docx.enum.text import WD_ALIGN_PARAGRAPH from docx.shared import Inches, Pt p = doc.add_paragraph('Summary') p.alignment = WD_ALIGN_PARAGRAPH.RIGHT p.paragraph_format.space_before = Pt(12) p.paragraph_format.space_after = Pt(6) p.paragraph_format.line_spacing = 1.5 p.paragraph_format.left_indent = Inches(0.5)

space_before and space_after set spacing outside the paragraph. line_spacing can be a float (multiplier) or a Pt value. Indentation can be set for left, right, and first line. For hanging indents, use first_line_indent with a negative value.

These settings are applied to the paragraph, not to individual runs. If you need different spacing for different sections, create separate paragraphs and set their paragraph_format independently.

Using Styles for Consistent Formatting

Hard-coding fonts and spacing on every paragraph quickly becomes unmaintainable. python-docx supports Word styles, which let you define formatting once and reuse it.

Access a built-in style and modify it:

python
from docx.shared import Pt style = doc.styles['Normal'] style.font.name = 'Arial' style.font.size = Pt(11) style.paragraph_format.space_after = Pt(6)

You can also create custom styles:

python
from docx.enum.style import WD_STYLE_TYPE from docx.shared import Pt custom = doc.styles.add_style('CustomHeading', WD_STYLE_TYPE.PARAGRAPH) custom.base_style = doc.styles['Heading 1'] custom.font.name = 'Georgia' custom.font.size = Pt(20) custom.font.bold = True

Then apply the style to a paragraph:

python
p = doc.add_paragraph('Chapter 1', style='CustomHeading')

Using styles reduces repetition and makes global changes trivial. When you modify a style, all paragraphs using it update automatically. This is especially useful for long documents where you need consistent headings, body text, and captions.

Performance and Compatibility Considerations

Generating documents with many images or large amounts of content can affect memory and file size. python-docx loads the entire document into memory, so for very large files, consider streaming or splitting into multiple documents. Images are embedded as-is; a 10 MB image will bloat the output file. Resize images before insertion if possible, using a library like Pillow, and then insert the resized version.

Compatibility is another concern. python-docx only works with .docx (Office Open XML) files, not the older .doc format. If you need .doc support, you must use a different tool or convert via LibreOffice. Also, font availability depends on the system where the document is opened. A font name that exists on your machine may not exist on the recipient's, causing Word to substitute a fallback. For maximum portability, stick to common fonts like Arial, Calibri, or Times New Roman, or embed fonts in the document (which python-docx does not support directly).

Finally, be aware that python-docx does not validate the formatting you set. For example, setting line_spacing to a negative value can produce an invalid document that may not open in Word. Always test the generated file with a real Word processor, especially when you use advanced features like custom styles or complex alignment.

Handling Edge Cases: Images with Captions and Inline Text

A common pattern is to add a caption below an image. You can do this by adding a separate paragraph after the image:

python
p_img = doc.add_paragraph() p_img.alignment = WD_ALIGN_PARAGRAPH.CENTER p_img.add_run().add_picture('chart.png', width=Inches(4)) p_cap = doc.add_paragraph('Figure 1: Quarterly revenue') p_cap.alignment = WD_ALIGN_PARAGRAPH.CENTER p_cap.runs[0].font.size = Pt(9) p_cap.runs[0].font.italic = True

If you need text to wrap around an image, python-docx does not expose a high-level API. You would have to manipulate the underlying XML to set the image's wrap type. This is rarely worth the effort; a simpler approach is to use a table with two cells: one for the image and one for the text. Tables give you predictable layout without fighting the document model.

Another edge case is inserting an image inline with text. Add separate runs for the text and the image:

python
p = doc.add_paragraph() p.add_run('Before ') p.add_run().add_picture('icon.png', width=Inches(0.5)) p.add_run(' after')

This places the image inline with the text, which is useful for icons or inline graphics. Note that the run's font formatting does not affect the image.

Final Technical Note: Working with Sections and Page Formatting

For complete control over page size, margins, and orientation, you need to work with sections. python-docx creates a default section when you instantiate a Document. You can modify it:

python
section = doc.sections[0] section.page_width = Inches(8.5) section.page_height = Inches(11) section.left_margin = Inches(1) section.right_margin = Inches(1)

If your document needs different headers or footers for different parts, add new sections with doc.add_section(). Each section can have its own page setup. This is often necessary for reports that mix portrait and landscape pages or that have different margins for appendices.

Combining images, fonts, paragraph formatting, and section properties gives you a complete toolkit for generating professional Word documents. The key is to plan the document structure before writing code: define styles for recurring elements, decide where images go, and set section properties early. This keeps the generation logic clean and the output predictable.
